| Interface | 3 10/100/1000Mbps RJ45 LAN Ports 1 10/100/1000Mbps RJ45 WAN Port 1 VDSL2 Port 1 FXS Ports 1 USB 2.0 Port |
|---|---|
| Button | Power On/Off Button, WPS On/Off Button, Wireless On/Off Button, Reset Button |
| External Power Supply | 12V/1.5A |
| Wireless Standards | IEEE 802.11ac/n/a 5GHz, IEEE 802.11b/g/n 2.4GHz |
| IEEE Standards | IEEE 802.3, IEEE 802.3u, 802.3ab |
| VDSL2 Standards | ITU G.993.2, Up to 35b profile ITU-T G.993.5 (G.vector) ITU-T G.998.4 (G.INP) |
| ADSL Standards | Full-rate ANSI T1.413 Issue 2 ITU-T G.992.1 (G.DMT) ITU-T G.992.2 (G.Lite) ITU-T G.994.1 (G.hs) ITU-T G.995.1 |
| ADSL2 Standards | ITU-T G.992.3 (G.DMT.bis) ITU-T G.992.4 (G.lite.bis) |
| ADSL2+ Standards | ITU-T G.992.5 |
| Dimensions ( W x D x H ) | 8.4 × 5.7 ×3.2 in (214.0 × 144.5 × 80.0 mm) |
| Antenna | Internal antennas |
| Antenna Gain | 3 x 2dBi for 2.4GHz and 4 x 2dBi for 5GHz |
| Frequency | 2.4GHz and 5GHz (Supports DFS) |
|---|---|
| Signal Rate | 867Mbps at 5GHz, 300Mbps at 2.4GHz |
| Wireless Functions | Enable/Disable Wireless Radio, WMM, Wireless Statistics |
| Wireless Security | 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK encryptions |
| DHCP | Server, Client, DHCP Client List, Address Reservation, DHCP Relay |
| Transmission Power | <20dBm (2.4GHz), <23dBm (5GHz Band1 & Band2), <30dBm (5GHz Band3) |
| Wireless Schedule | Support 2.4GHz and 5GHz Wireless Schedule |
| Quality of Service | ATM QoS, QoS |
|---|---|
| Advanced Features | Parental Controls, Network Address Translation(NAT), Port Mapping (Grouping), Static Routing, RIP v1/v2 (optional), DNS Relay, DD NS, IGMP V1/V2/V3 |
| Security | NAT Firewall, SPI Firewall, Access Control, Service Filtering, Denial of Service (DoS), SYN Flooding, Ping of Death, IP and MAC Address Binding |
| Management Features | Web Based Configuration (HTTP / HTTPS ), Remote management, Command Line Interface, SSL for TR-069, SNMP v1/2c, Firmware Up grade, Diagnostic Tools, Web Based Firmware Upgrade |
| Port Forwarding | Virtual Server, Port Triggering, DMZ, ALG, UPnP |
| Dynamic DNS | DynDns, NO-IP |
| VPN | OpenVPN, PPTP VPN, IPSec VPN |
| Protocols | Support IPv4 and IPv6 |
| ATM/PPP Protocols | ATM Forum UNI3.1/4.0, PPP over ATM (RFC 2364), PPP over Ethernet (RFC2516), IPoA (RFC1577/2225), MER\IPoE (RFC 1483 Routed), Bridge (RFC1483 Bridge), PVC – Up to 8 PVCs |
| USB Sharing | Support Samba (Storage) / FTP Server / Media Server |
| Guest Network | 2.4GHz guest network, 5GHz guest network |
| IPSec VPN | Support up to 10 IPSec VPN tunnels |
| Certification | CE |
|---|---|
| System Requirements | Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7, 8, 8.1, 10, MAC OS, NetWare, UNIX or Linux Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0 , or other Java-enabled browser Cable or DSL Modem |
| Environment | Operating Temperature: 0℃–40℃(32℉–104℉) Storage Temperature: -40℃–70℃(-40℉–158℉) Operating Humidity: 10%–90% non-condensing |
